CABUR - XCSF120CP POWER SUPPLY 120-230VAC OUTPUT 120W 24VDC Single phase power supply IN: 120–230 Vac / OUT: 24 Vdc 5 A Single phase and DC input Short circuit, overload, input and output overvoltage protections Over temperature protection Suitable for applications that require high reliability and performance Smart alarm contact, signals when output voltage drops more than 10% High overload capability to ensure the protections selectivity and start-up of heavy loads SPECIFICATIONS Specifications Manufacturer Part Number XCSF120CP Item Number XCSF120CP Manufacturer ASI-Automation Systems Interco Product Series CSF Family Series ASI-Automation Systems Interco Power Supplies, CSF Series Power 120 W Nominal Input Voltage (AC) 120 VAC, 208 VAC, 240 VAC Input Voltage (AC) 90-264 VAC Input Frequency 47-63 Hz Phase (Input) 1 Nominal Output VDC 24 VDC Output VDC 23-27.5 VDC Output Current 5 A Number of Outputs 1 Mounting DIN Rail Enclosed Yes Encapsulated No Input Volts-Auto-Ranging Yes Output Voltage Adj. Yes Overvoltage Protection Yes Overload Protection Yes Short Circuit Protection Yes Power Factor Correction No Parallel Operation Yes Remote Sensing No Remote On/Off Control No Efficiency % 86 % Operating Temperature -4-140 °F Approvals CE, cULus, cURus, UL508, UL60950 RoHS Yes Net Weight 1.015 lbs Gross Weight 1.17 lbs
